High Temperature High Pressure Reactor for Fischer-Tropsch Reaction, Hydrogenation Reaction.
Detais
It is suitable for chemical and chemical reactions requiring the simultaneous determination of temperature, addition of inert gases, pressure, pH, conductance and redox potential for precise chemical synthesis reactions. Application examples: catalysis, high temperature and pressure synthesis, kinetic testing, Fischer-Tropsch reactions, hydrogenation reactions.
The high temperature autoclave WCGF-100ml (Xi'an) is used for precise chemical synthesis reactions where temperature, addition of inert gas, pressure, pH, conductance and redox potential need to be measured simultaneously.
Application examples: catalysis, high-temperature and high-pressure synthesis, kinetic testing, Fischer-Tropsch reactions, hydrogenation reactions.
Feature
It can be used individually or in parallel or in series.
It can be connected to a computer via RS232 communication interface for printing and displaying historical values and actual curves required by the user, and the whole system can be monitored in real time via software.
Technical Parameters
| Material | Kettle body in pure titanium / or 316L stainless steel, worktop in 316L stainless steel |
| working pressure | 8MPa |
| Working temperature | ≤400ºC |
| Heating mode | Direct heating in the reactor envelope, simple and convenient, fast temperature rise, strong usability, direct heating and temperature control with a series of electric fibre furnaces / or electric heating rings |
| Heating power | 300W-500W |
| Control accuracy | ±1ºC |
| Stirring speed | 0-1500RPM |
